23L Ethylene Oxide Sterilizer Scitek Global
Ethylene oxide
sterilizer is mainly through its non-specific alkylation with genetic materials
such as protein and DNA / RNA in microorganisms, resulting in the denaturation
of proteins and genetic materials, and finally the death of microorganisms due
to blocked metabolism.
Features
1.
Humidification: Utilizes steam degradation analysis method with
built-in steam generator for comprehensive and uniform humidification and
heating while minimizing water mist.
2.
3.5" LCD screen: Equipped with a filter for stability, prolonging
the service life and accuracy of the control screen.
3.
Power-off memory function: Preserves sterilization data and
automatically resumes unfinished work procedures in case of accidents or power
loss.
4.
Safety protection function: Includes alarm protection for
abnormal temperature, ultra-high temperature, abnormal pressure, low vacuum
rate, residual faults, phase sequence errors, and power shortage in the
sterilization chamber to prevent further issues.
5.
Ethylene Oxide Consumable: Steam EO sterilization pouch roll,
chemistry indicator strip, biological indicator, chemistry indicator tape,
chemical indicator label, EO sterilization gas, medical non-woven fabric,
sealing machine, EO sterilization gas.
Specification:
|
Parameter / Specification
|
Value
|
|
Model
|
ST-EO40
|
|
Effective Volume
|
23L
|
|
Product Form
|
Desktop
|
|
Heating Method
|
Electric heating
|
|
Working Temperature
|
50℃ ±3℃
|
|
Selected Gas
|
Pure ethylene oxide gas
|
|
Sterilization Time
|
0-99 hours adjustable
|
|
Temperature Display
|
3.5 inch LCD display
|
|
Maximum Anti-stress
Value
|
-140kpa
|
|
Voltage/Frequency(V/Hz)
|
AC220V, 50Hz
|
|
Power
|
3.3KW
|
|
Size(WxDxH)
|
Internal (mm)
|
Diameter x Depth: Ø246x450
|
|
Size(WxDxH)
|
External (mm)
|
730x510x410
|
|
Shipping Size
(WxDxH) (mm)
|
900x700x600
|
|
N.W./G.W. (kg)
|
56/76
|
