Model

ICB-B70E

ICB-B150E

ICB-B250E

ICB-B70

ICB-B150

ICB-B250

Cycle Mode

Forced convection

Function

Temp. Range

0～65℃

Temp. Resolution Ratio

0.1℃

Temp. Motion

High Temp.: ±0.5℃      Low Temp.: ±1℃

Temp. Uniformity

±1.5℃

Structure

Inner Chamber

Mirror Stainless Steel

Outside Material

Cold rolling steel electrostatic spraying exterior

Insulation Layer

Polyurethane

Heater

Stainless steel heater

Power Rating

0.8kW

1.0kW

1.2kW

Compressor

Air-cooled hermetic compressor

Cryogen

R134a

Defrost Structure

Automatic control intelligent defrosting

Test Hole

Inner diameter 43mm(one)

Controlled External Power Supply

Outer universal socket (one), inner waterproof socket(one)

Temp. Setting Mode

Touch button setting

Temp. Display Mode

Measuring temperature: LCD upper screen; setting temperature: the lower row

Timer

E model：0～99.9h    Without E  model：0～99.9h×30 segment(with timing wait function)

Operation Function

E model：Fixed value operation、timing function, auto stop.

Without E model：Program operation

Sensor

PT100

Additional Function

E model：LED light, Deviation correction, Menu key lock, Power failure parameter memory

 Without E model: Loop self diagnosis, sensor fault alarm

Safety Device

Over temperature alarm

Specification

Inner Chamber Size(W×L×H)(mm)

415×350×500

490*400*750

500*500*950

Exterior Size (W×L×H)(mm)

571×591×1051

646*641*1301

656*741*1501

Packing Size (W×L×H)(mm)

676×680×1235

751*730*1490

761*830*1690

Volume

70L

150L

250L

Load per rack

15kg

Shelf Number

5

9

12

Shelf Space

60mm

Power Supply Current Rating

AC220V/2.3A

AC220V/3.6A

AC220V/5.5A

NW/GW (kg）

69/92

86/114
