Stackable CO₂ Incubator Shaker ICB-C160ST Scitek Global
Features
1. Three stackable layers structure
2. Pull out rail platform
3. 7-inch color touch screen, the display has a real time temperature and speed curve display function.
4. Automatic defrost function
5. High precision speed and temperature control
6. Memorized and protected operating parameters
7. Function of encrypted and locked operating parameters
8. Continuously running or timing
9. Automatic analyzing, listing table, charting and printing on downloaded dates.
10. Multi-steps rotate speed, temperature and time control systems
11. Unique slow-start design, unique drive system and advantaged air duct design
12. High quality servo motor
13. Slow accelerate and decelerate design
14. High pressure water rinses the bottom of the chamber and platform.
15. Open door protection.
16. A remote WIFI operation as an optional.
Specification
|
Model
|
ICB-310SCT
|
|
Display
|
7-inch color touch screen
|
|
Controller / Drive
|
PID / Multidimensional drive
|
|
Circulation / Shaking
|
Forced convection / Convolution
|
|
Capacity
|
310L
|
|
Temp. Range
|
4~65℃
|
|
Temp. Accuracy / Uniformity
|
±0.1℃ / ±0.6℃ (at 37℃)
|
|
Cyclotron Freq. Range
|
20-350 rpm/min (top floor 20-300)
|
|
Cyclotron Freq. Sensitivity
|
±1 rpm
|
|
CO2 Density / Orbit Range
|
0~20.0% / Φ50 mm
|
|
Timing Range
|
0-999.9 h/min (continuous duty)
|
|
Standard Capacity
|
Flask clamp: 500ml × 33
|
|
Max. Capacity (per unit)
|
Flask clamp: 250ml×53 / 500ml×35 / 1000ml×20 / 2000ML×11
|
|
Platform / Power Supply
|
One platform / AC220V±10% (50/60Hz), 110V (60Hz)
|
|
Power / Size (W×D×H)
|
1800W / 1420 × 820 × 630 mm
|
|
Gross Weight
|
300 kg (per unit)
|
